Onboard hardware DSP with symphony ECS channel strip: 3-band EQ, high-pass filter, compressor and drive control
Gain for microphone signals: + 62dB
Phantom power: +48V
Pad and phase rotation switchable via the Apogee Control 2 software
Switchable direct monitoring
Switchable loopback function for streaming applications
USB bus-powered
XLR/TRS combo input for microphones and line signals
6.3 mm Jack input for instruments and line signals
2 Line outputs: 6.3 mm jack, balanced
Stereo headphone output: 6.3 mm jack
USB-C port
Incl. Ableton Live Lite, Apogee Control 2 software (macOS, iOS, Windows), Apogee Soft Limit plug-in (download), USB-C cable with included USB-C to USB-A adapter
Dimensions (WxDxH): 164 x 117 x 51 mm
Weight: 731 g
Available sinceSeptember 2022
Item number551275
Sales Unit1 piece(s)
Recording / Playback Channels2x2
Number of Mic Inputs1
Number of Line Inputs2
Instrument Inputs1
Number of Line Outs2
Headphone Outs1
Phantom powerYes
Number of S/PDIF Connectors0
Number of ADAT Connectors0
Numer of AES/EBU Connectors0
Number of MADI Connectors0
Ethernet0
Other ConnectorsUSB-C
MIDI interfaceNo
Word ClockNo
Max. sample rate (kHz)192 kHz
Max. resolution in bit24 bit
USB Bus-PoweredYes
Incl. power supplyNo
USB Version2.0
Width in mm164 mm
Depth in mm117 mm
Height in mm51 mm
Connection FormatUSB port Type C
Included in deliveryAbleton Live Lite, Apogee Control 2 Software (macOS, iOS, Windows), Apogee Soft Limit Plugin (Download), USB-C cable, USB-C to USB-A Adaptor
